Stainless steel = SS pump tubes with Ex-approval, outside Ex-areas max. 90 and 120°C
Stainless steel pump tubes suitable for all neutral, low viscous media as organic and inorganic diluted acids and alkalies.
These pumps are also ATEX compliant meaning they can be used for pumping highly combustible media such as solvents or gasoline and for use in explosive environments.
Suitable for flammable media up to temperature class 4 and use in Ex-zone 0.
The pump tubes in stainless steel with a carbon bearing approved for the food sector can be used in the food industry and the beverage industry.
Drive shaft made of stainless steel 316Ti.
Hose connection 1″ included (¾“ or 1¼“ also possible).
EC type examination certificate number ZELM 09 ATEX 0424X.
Maximum medium temperature 90°C (with PTFE rotor) or 120°C (with stainless steel rotor) outside Ex-areas.
Standard tube lengths are 1000mm for 200 L drums or 1200mm for IBC. Other lengths available from 700mm to 3,000mm.
Other accessories available such as wall hangers, flow meters and nozzles
Enquire here for more information or to request a quote:
Can I use the same pump to decant from 200 L drums and IBCs? Yes you can. We would supply a 1200 mm long spear, so you can fully decant the IBC but when you use the pump on the 200 L drums, it would just be 200 mm longer.
